MODEL NUMBER: 1199T 5
INSTALLATION INSTRUCTIONS
Customer Service: 561-274-2110
www.decolav.com LET YOUR DREAMS COME ALIVE, YOUR PASSIONS BECOME
REALITY, BE THE ENVY OF YOUR NEIGHBORS ®
Hard
Drain
Overflow
Washer
Washer
Elbow
Small Clear
Washer
Black
Overflow Nut
Overflow Nut
Flexible Pipe
Black Washer
Tailpiece
Drain Nut
Clear Thick
Washer
B
A
C
A
Apply Silicone Here
Figure #6
• STEP #4
o Assemble Drain and Overfl ow System to Glass Basin as shown.
• STEP #5
o Place Assembled Basin above Tempered Glass Panels to check for alignments.
o Remove Assembled Basin from Unit, apply Silicone along the upper edge of Tempered Glass Panels,
and replace Assembled Basin. Align Assembled Basin.
o Do not try to clean off Silicone excess at this point. It is easier to clean Silicon once curing has taken
place. After curing, carefully, at avoid damaging the glass, remove Silicon from Unit using a razor
blade. Follow additional instruction suggested by Silicon Manufacturer.
o Refer to Figure #6
