recOMMended tOOls
rOughing-in diMensiOns
MOdel nuMBer: 1300 series
2
MOdel nuMBer: 1300 series
3
customer service: 561-274-2110
www.decolav.com
Let your dreams come aLive, your passions
become reaLity, be the envy of your neighbors
®
tape measure
adjustable Wrench
drill Level
pipe Wrench plumber’s putty or caulking putty Knife
scroll saw pencil
17" [43.18 cm]
14" [35.56 cm]
7 1/4"
[18.415 cm
]
6" [15.24 cm]
8" [20.32 cm]
11 3/
4" [29.845 cm
]
13 3/
4
" [34.925 cm]
13
3
/4" [34.925 cm
]
34" [86.36 cm] 34" [86.36 cm]
16
1/
4" [41.275 cm
]
17" [43.18 cm]
8" [20.32 cm]
19 1/4" [48.895 cm]
19 1/4" [48.895 cm]
2" [5.08 cm]
2 1/2" [6.35 cm]
3 3/4" [9.525 cm]
1 1/4"
[3.175 cm]
1 3/4"
[4.445 cm]
Finished Wall
Cutout Area
(If Drop in)
Faucet Hole
Drain
Hole
Cutout Area
(if Undermount)
Mounting Clips
(If Needed)
Fitting Line Sugg.
Sugg.
Finished Wall
Finished Floor
Finished Floor
Side View Front View
Top View
Suggested Suggested
Supplies as
Required
Waste
