SHARC USB EZ-Extender Manual
A-1
A USB EZ-EXTENDER BILL OF
MATERIALS
The bill of materials corresponds to
“USB EZ-Extender Schematic” on
page B-1
. Please check the latest schematic on the Analog Devices Web
site:
.
Ref. Qty. Description
Reference
Designators
Manufacturer
Part Number
1
1
SN74LVC1G32
SOT23-5
U9
TI
SN74LVC1G32DBVRE4
2
1
SN74LVC1G08
SOT23-5
U11
TI
SN74LVC1G08DBVR
3
1
NET2272
TQFP64
U10
NET CHIP NET2272REV1A-LF
4
1
PI3B16234
TSSOP56
U1
PERICOM
SEMI
PI3B16234AE
5
1
30MHZ OSC010 Y1
ECLIPTEK
E2SAA10-30.000M
6
1
PI3B16226
BQSOP40
U4
PERICOM
SEMI
PI3B16226BE
7
1
SN74ALVCH163
73 TSSOP48
U2
TI
SN74ALVCH16373DGGR
G4
8
1
ADP3330ARTZ-2
5 SOT23-6
VR1
ANALOG
DEVICES
ADP3330ARTZ-2.5-R7
9
1
USB 4PIN
CON009
P4
MILL MAX 897-43-004-90-000
000
