SHARC USB EZ-Extender Manual 2-3
USB EZ-Extender Hardware Reference
Table 2-1 describes the jumper settings and functionality. The jumper, by
default, must have no jumpers on any of its pins.
L
When using the extender with an ADSP-21262 or ADSP-21364
EZ-KIT Lite, you must not place any jumpers on
JP1 . Placing a
jumper on JP1 can damage the extender card and/or the EZ-KIT
Lite. When using the extender with an ADSP-21369 EZ-KIT Lite,
you must place the jumper on
JP1 .
Table 2-1. JP1 Settings
EZ-KIT Lite JP1 Setting
ADSP-21262/ADSP-21364 No jumpers (default)
ADSP-21369 Installed
