USB EZ-Extender Interface
You can reset the NetChip 2272 device by asserting
LOW
these flag pins:
•
FLAG2
on the ADSP-21262 and ADSP-21364 processors
•
FLAG0
on the ADSP-21369 processor
The USB interrupt request pin (IRQ) line of the extender connects to
FLAG1
on the ADSP-21262, ADSP-21364, and ADSP-21369 processors.
This flag pin may be used for push buttons or LEDs on the respective
EZ-KIT Lites; consequently, the user must make the proper changes to
that EZ-KIT Lite.
When writing to and reading from the USB device using the EZ-KIT
Lites, use memory addresses listed in
.
Table 1-1. USB Device Memory
EZ-KIT Lite
Starting Address
Ending Address
ADSP-21262
0x0100 6C00
0x0100 6FE0
ADSP-21364
0x0100 6C00
0x0100 6FE0
ADSP-21369
0x0C00 0000
0x0C00 03E0
