8

6. Remove outer spring from Core Assembly (Seal Kit Assembly) and pull Core Assembly out.

7. Inspect Valve Body for O-rings that may have been left in and remove.

8. Remove the sleeve from the Core Tube and remove the O-ring.

9. Locate parts from the Seal Kit.

Locate and remove

both O-rings

Inspect Seal Kit parts and

insure the small spring is

in the core.


CAUTION: Do not unscrew any part
of the seal kit during inspection or
reassembly. Any change in length
will affect valve performance.
