2.4 RATING PLATE INFORMATION
THIS IS A GAS-FIRED UNVENTED
ROOM HEATER THAT REQUIRES
ADEQUATE COMBUSTION AND
VENTILATION AIR.THIS APPLIANCE
IS NOT FIELD CONVERTIBLE FOR
USE WITH OTHER FUELS.
DIAGRAM TO AID THE OPERATION
OF THIS FIREPLACE
FLAME
ADJUSTMENT
ON / OFF
CONTROL
IGNITOR
**ABOVE 2,000FT, CONSULT LOCAL AUTHORITY HAVING JURISDICTION
NOT FOR USE WITH SOLID FUEL.
B
A
45
o
C
MINIMUM CLEARANCE TO COMBUSTIBLE MATERIALS
A 4”
B 2"
C 2"
48” MINIMUM TO CEILING FROM STOVE TOP
SERIAL NUMBER
GVFS20
W385-0337 / K
WOLF STEEL LTD.
24 NAPOLEON ROAD. BARRIE, ONTARIO L4M 0G8 CANADA
CONFORMS TO: ANSI Z21.11.2b-2009, UNVENTED GAS FIRED ROOM HEATER
THIS UNIT IS NOT APPROVED FOR
BEDROOM, BATHROOM AND
BED-SITTING ROOM INSTALLATION.
GVFS20-N MODEL GVFS20-P
**0-2000FT (0-610m)
ALTITUDE
**0-2000FT (0-610m)
23,000 BTU/h
INPUT
23,000 BTU/h
18,000 BTU/h
REDUCED INPUT
18,000 BTU/h
9700539 (WSL)
4001657 (NGZ)
4001658 (NAC)
4001659 (WUSA)
MANIFOLD
PRESSURE: 3.5" WATER COLUMN
MANIFOLD PRESSURE: 10" WATER COLUMN
MINIMUM SUPPLY PRESSURE: 4.5" WATER COLUMN
MINIMUM SUPPLY PRESSURE: 11" WATER COLUMN
MAXIMUM SUPPLY PRESSURE: 7.0" WATER COLUMN
MAXIMUM SUPPLY PRESSURE: 13" WATER COLUMN
SIT CONTROL: # 820.638
SIT CONTROL: # 820.636
OPERATING PILOT OXYPROTECTOR: # 8214
OPERATING PILOT OXYPROTECTOR: # 8436
WARNING: DO NOT ADD ANY MATERIAL TO THE APPLIANCE,
WHICH WILL COME IN CONTACT WITH THE FLAMES, OTHER
THAN THAT SUPPLIED BY THE MANUFACTURER WITH THE
APPLIANCE.
SCREEN MUST BE IN PLACE WHILE THE APPLIANCE IS IN
OPERATION.
ELECTRICAL RATING: 115V 0.82AMP, 60HZ
OPTIONAL FAN KIT: GS-64KT
INSTALLER: It is your responsibility to check off the appropriate box on the rating plate according to
the model, venting and gas type of the appliance.
For rating plate location, see “INSTALLATION OVERVIEW” section.
This illustration is for reference only. Refer to the rating plate on the appliance for accurate information.
