2
W415-0559 / D / 05.09.12
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW 3
2.0 INTRODUCTION 4
2.1 DIMENSIONS 5
2.2 GENERAL INSTRUCTIONS 5
2.3 GENERAL INFORMATION 6
2.4 RATING PLATE INFORMATION 7
3.0 INSTALLATION 8
3.1 COMBUSTION AND VENTILATION AIR PROVISIONS 8
3.2 DETERMINING CONFINED OR UNCONFINED SPACE 9
3.3 GAS INSTALLATION 10
3.4 OPTIONAL WALL SWITCH / THERMOSTAT 11
3.5 MOBILE HOME INSTALLATION 11
4.0 FINISHING 12
4.1 CAST FRONT INSTALLATION AND REMOVAL 12
4.2 SCREEN INSTALLATION AND REMOVAL 12
4.3 LOGO PLACEMENT 12
4.4 LOG PLACEMENT 13
5.0 OPTIONAL BLOWER INSTALLATION 14
5.1 BLOWER INSTALLATION AND CONNECTION 14
5.2 SWITCH CONNECTIONS 14
6.0 OPERATION 15
7.0 ADJUSTMENT 16
7.1 VENTURI ADJUSTMENT 16
7.2 FLAME CHARACTERISTICS 16
8.0 MAINTENANCE 17
8.1 OXYGEN DEPLETION SENSOR PILOT CLEANING 17
8.3 PILOT INDICATOR LIGHT BATTERY REPLACEMENT 18
8.2 ORIFICE REPLACEMENT 18
9.0 REPLACEMENTS 19
10.0 TROUBLE SHOOTING 21
11.0 WARRANTY 24
12.0 SERVICE HISTORY 25
