6
W415-0297 / P / 02.03.12
When the appliance is installed at elevations above 2,000ft, and in the absence of specifi c recommendations
from the local authority having jurisdiction, the certifi ed high altitude input rating shall be reduced at the rate of
4% for each additional 1,000ft.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible
for use with other gases, unless a certifi ed kit is used.
No external electricity (110 volts or 24 volts) is required for the gas system operation.
Expansion / contraction noises during heating up and cooling down cycles are normal and to be expected.
This appliance is equipped with a pilot light safety system referred to as an oxygen depletion sensor and is
designed to turn off the appliance if not enough fresh air is available.
Use only accessories designed for and listed with your specifi c appliance.
Ceiling fans or oscillating type fl oor fans can cause fl ame impingement if directing air at the appliance. Imping-
ing fl ames will cause soot or carbon that may enter into living area. Try reversing ceiling fan or re-directing fl oor
fans to prevent sooting.
2.4 RATING PLATE INFORMATION
CERTIFIED UNDER: ANSI Z21.11.2a-2008 VOLUME II, UNVENTED ROOM HEATER
W385-0247 / G
SERIAL NUMBER: GVF36
WOLF STEEL LTD.
24 NAPOLEON ROAD, BARRIE, ON, L4M 0G8 CANADA
THIS APPLIANCE MAY BE INSTALLED IN AN AFTERMARKET,
PERMANENTLY LOCATED, MANUFACTURED (MOBILE) HOME, WHERE
NOT PROHIBITED BY LOCAL CODES. THIS APPLIANCE IS ONLY FOR USE
WITH THE TYPE OF GAS INDICATED ON THE RATING PLATE. THIS
APPLIANCE IS NOT CONVERTIBLE FOR USE WITH OTHER GASES. THIS IS A GAS-FIRED UNVENTED ROOM HEATER THAT REQUIRES
ADEQUATE COMBUSTION AND VENTILATION AIR. THIS UNIT IS NOT
APPROVED FOR BEDROOM, BATHROOM AND BED-SITTING ROOM
INSTALLATION.
GVF36N / CVF36N MODEL GVF36P / CVF36P
**0-2000FT (0-610m) ALTITUDE 0-2000FT (0-610m)**
30,000 BTU/h INPUT 30,000 BTU/h
20,000 BTU/h REDUCED INPUT 22,000 BTU/h
MANIFOLD PRESSURE: 3.5" WATER COLUMN MANIFOLD PRESSURE: 10" WATER COLUMN
MINIMUM SUPPLY PRESSURE: 4.5" WATER COLUMN MINIMUM SUPPLY PRESSURE: 11" WATER COLUMN
MAXIMUM SUPPLY PRESSURE: 7.0" WATER COLUMN MAXIMUM SUPPLY PRESSURE: 13" WATER COLUMN
SIT CONTROL: #820637 SIT CONTROL: #820636
OPERATING PILOT OXYPROTECTOR: #8214 OPERATING PILOT OXYPROTECTOR: #8404
** ABOVE 2,000FT, CONSULT LOCAL AUTHORITY HAVING JURISDICTION
NOT FOR USE WITH SOLID FUEL.
WARNING: FIREPLACE SCREENS MUST BE CLOSED WHILE IN OPERATION. DO NOT ADD ANY MATERIAL TO THE APPLIANCE, WHICH
WILL COME IN CONTACT WITH THE FLAMES, OTHER THAN THAT SUPPLIED BY THE MANUFACTURER WITH THE APPLIANCE. DONOT USE BLOWER INSERT, HEAT EXCHANGER
INSERT OR OTHER ACCESSORIES NOT APPROVED FOR USE WITH THIS HEATER. IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTAINANCE CAN
CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. REFER TO THE OWNER'S INFORMATION MANUAL PROVIDED WITH THIS APPLIANCE. INSTALLATION AND
SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER, SERVICE AGENCY OR THE GAS SUPPLIER.
MINIMUM CLEARANCE TO COMBUSTIBLE MATERIALS:
TOP / SIDES / BACK / FLOOR 0”
RECESSED DEPTH
13 1 / 2 “
MANTEL 8”*
* MINIMUM CLEARANCE TO A COMBUSTIBLE MANTLE IS 12” WHEN USING A
CATALYTIC DOOR. MAXIMUM HORIZONTAL EXTENSION: 2". SEE INSTRUCTION
MANUAL FOR GREATER EXTENSIONS.
ELECTRICAL RATING: 115V 0.82AMP, 60HZ
OPTIONAL FAN KIT: GZ550-KT
9700539 (WSL) 4001657 (NGZ)
4001658 (NAC) 4001659 (WUSA)
For rating plate location, see “INSTALLATION OVERVIEW” section.
This illustration is for reference only. Refer to the rating plate on the appliance for accurate information.
SAMPLE SAMPLE
HE HE A A TE TE A A R R
ON ON , L4 , L4 M 0 M 0
GAS- GAS- FIR FIR UNVE UNVE
U U A A TE TE A A COMB COMB USTI USTI ON ON A A
R R OVE OVE D D FO FO R R BE BE DR DR OO OO B B A A T T A A HR HR
L L A A L L TIO TIO A A N N . .
OD OD EL EL GVF GVF 3 3
ALTI ALTI TUDE TUDE 0-20 0-20
INPU INPU T T 30 30
DU DU CED CED INPU INPU T T
PL PL
C C OLUM OLUM MANI MANI FO FO
ER ER COLU COLU MN MN MINI MINI MUM MUM
ER C ER C OLUM OLUM N N MAXI MAXI MUM MUM S S
OL: OL: #820 #820 637 637 T T CONT CONT R R
P P ROTE ROTE CTOR CTOR : : #821 #821 4 4 OPER OPER AT AT
2, 2, 000F 000F T, C T, C ONSU ONSU LT L LT L OCAL OCAL AUT AUT HO HO
NO NO T T FO FO R R US US E E WI WI TH TH
MUS MUS T B T B E C E C LOS LOS ED ED WH WH
ER ER THAN THAN THA THA T SU T SU PPLI PPLI ED B ED B Y T Y T
VED VED FOR FOR USE USE WIT WIT H TH H TH IS H IS H EATE EATE
Y O Y O R LO R LO SS O SS O F LI F LI FE. FE. REFE REFE R TO R TO
INS INS TALL TALL ER, ER, SERV SERV ICE ICE AG AG
IBLE IBLE MAT MAT ERIA ERIA LS: LS:
0” 0”
13 13 1 1 / / 2 2 “ “
8 8
4001 4001 657 657 (N (N
001 001 659 659 (WUS (WUS A) A)
PL PL PL PL
