21
W415-0297 / P / 02.03.12
10.0 REPLACEMENTS
Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally
all parts can be ordered through your Authorized dealer / distributor.
FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE ORIGINAL INVOICE WILL BE
REQUIRED TO HONOUR THE CLAIM.
When ordering replacement parts always give the following information:
•
Model & Serial Number of appliance
• Installation date of appliance
• Part number
• Description of part
• Finish
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR
FURTHER INFORMATION, CONTACT YOUR AUTHORIZED DEALER.
41.1
FAILURE TO POSITION THE PARTS
IN ACCORDANCE WITH THIS
MANUAL OR FAILURE TO USE ONLY
PARTS SPECIFICALLY APPROVED
WITH THIS APPLIANCE MAY
RESULT IN PROPERTY DAMAGE OR
PERSONAL INJURY.
!
WARNING
COMPONENTS
REF PART NO. DESCRIPTION
1 W357-0001 PIEZO IGNITER
2 W662-0001 OXYGEN DEPLETION SENSOR SYSTEM - NG
2 W662-0005 OXYGEN DEPLETION SENSOR SYSTEM - LP
3* W680-0004 THERMOPILE
4 W725-0030 NATURAL GAS VALVE
4 W725-0031 PROPANE GAS VALVE
5* W385-0334 NAPOLEON LOGO
6* W750-0112 20FT OF WIRE
7 GL-664 ONE PIECE LOG SET (W135-0335)
8* W361-0016 GLOWING EMBERS
9* W550-0001 CHARCOAL EMBERS
10 W010-0764 PAN BURNER (NG)
10 W010-0987 PAN BURNER (LP)
11 W456-0039 #39 NATURAL GAS BURNER ORIFICE
11 W456-0053 #53 PROPANE GAS BURNER ORIFICE
12 W335-0050 HOOD
13 W565-0058 CURTAIN MESH
14 W555-0033 CURTAIN ROD
15* W080-0742 CURTAIN ROD BRACKET
16 W500-0194 PLATE COVER
17 W630-0010 BLACK TASSELS
ACCESSORIES
REF PART NO. DESCRIPTION
18* W660-0081 SWITCH, THERMOSTAT
19* F40 ON/OFF REMOTE
19* F50 THERMOSTATIC REMOTE
19* F50DR DESIGNER THERMOSTATIC REMOTE - RED
19* F50DY DESIGNER THERMOSTATIC REMOTE - GREY
19* F50DK DESIGNER THERMOSTATIC REMOTE - BLACK
20* W660-0013 MODULATING REMOTE
21* GD825N MODULATING REGULATOR NG
21* GD825P MODULATING REGULATOR LP
22* W660-0026 PROGRAMMABLE TIMER, BATTERY OPERATED
23 GZ550-1KT BLOWER KIT
24* W500-0033 VARIABLE SPEED SWITCH WALL MOUNTING PLATE
25* 111KT OUTSIDE AIR KIT
26* 112KT ADAPTOR PLATE FOR OUTSIDE AIR KIT
27 HOIK-3 ORNAMENTAL INSETS - BLACK
27 HOIG-3 ORNAMENTAL INSETS - GOLD
27 HOISS-3 ORNAMENTAL INSETS - SATIN CHROME
