2
W415-0297 / P / 02.03.12
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin
TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW
Hood, see “HOOD”
section.
Louvres, see “L36
LOUVRE INSTALLATION”
section.
Curtain Mesh, see
“GRATE AND LOG
PLACEMENT” section.
Logs, see “GRATE AND LOG
PLACEMENT” section.
Rating Plate, see “RATING
PLATE INFORMATION”
section.
1.0 INSTALLATION OVERVIEW 2
2.0 INTRODUCTION 3
2.1 DIMENSIONS 4
2.2 GENERAL INSTRUCTIONS 4
2.3 GENERAL INFORMATION 5
2.4 RATING PLATE INFORMATION 6
3.0 INSTALLATION 6
3.1 COMBUSTION AND VENTILATION AIR PROVISIONS 6
3.2 DETERMINING CONFINED OR UNCONFINED SPACE 7
3.3 GAS INSTALLATION 8
3.4 OPTIONAL WALL SWITCH / THERMOSTAT 9
3.5 MOBILE HOME INSTALLATION 9
4.0 FRAMING 10
4.1 MINIMUM CLEARANCE TO COMBUSTIBLES 11
4.2 MINIMUM CLEARANCES TO COMBUSTIBLE ENCLOSURES 12
4.3 MINIMUM MANTEL CLEARANCES 12
4.4 NAILING TAB INSTALLATION 13
5.0 FINISHING 13
5.1 GRATE AND LOG PLACEMENT 13
5.2 CHARCOAL EMBERS 14
5.3 GLOWING EMBERS 14
5.4 HOOD 14
5.5 LOUVRE INSTALLATION 15
5.6 LOGO PLACEMENT 15
6.0 OPTIONAL BLOWER INSTALLATION 15
7.0 OPERATION 17
8.0 ADJUSTMENT 18
8.1 VENTURI ADJUSTMENT 18
8.2 FLAME CHARACTERISTICS 18
9.0 MAINTENANCE 19
9.1 OXYGEN DEPLETION SENSOR PILOT CLEANING 19
9.2 CARE OF PLATED PARTS 19
10.0 REPLACEMENTS 20
11.0 TROUBLE SHOOTING GUIDE 22
12.0 WARRANTY 25
13.0 SERVICE HISTORY 26
