Napoleon Fireplaces GVF42 User Manual
Page 2
2
W415-0379 / E / 04.24.12
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin
TABLE OF CONTENTS
1.0 INSTALLATION
OVERVIEW
3
2.0 INTRODUCTION
4
2.1 DIMENSIONS
5
2.2 GENERAL
INSTRUCTIONS
5
2.3 GENERAL
INFORMATION
6
2.4
RATING PLATE INFORMATION
7
3.0 INSTALLATION
8
3.1
COMBUSTION AND VENTILATION AIR PROVISIONS
8
3.2
DETERMINING CONFINED OR UNCONFINED SPACE
8
3.3 GAS
INSTALLATION
10
3.4
OPTIONAL WALL SWITCH / THERMOSTAT
10
3.5 MOBILE
HOME
11
4.0 FRAMING
11
4.1
MINIMUM CLEARANCE TO COMBUSTIBLES
13
4.2 ALCOVE
INSTALLATION
14
4.3
MINIMUM MANTEL CLEARANCES
15
4.4 NAILING
TAB
INSTALLATION
15
5.0 FINISHING
16
5.1 GRATE
INSTALLATION
16
5.2 LOG
PLACEMENT
16
5.3 GLOWING
EMBERS
18
5.4 CHARCOAL
EMBERS
18
5.5 VERMICULITE
18
5.6 CHARCOAL
LUMPS
18
5.7 HOOD
18
5.8
L42 LOUVRE INSTALLATION
19
5.9 LOGO
PLACEMENT
19
6.0
OPTIONAL BLOWER INSTALLATION
20
7.0 OPERATION
22
8.0 ADJUSTMENT
23
8.1 VENTURI
ADJUSTMENT
23
8.2 FLAME
CHARACTERISTICS
23
9.0 MAINTENANCE
24
9.1
OXYGEN DEPLETION SENSOR PILOT CLEANING
24
9.2
CARE OF PLATED PARTS
25
10.0 REPLACEMENTS
25
11.0 TROUBLESHOOTING
GUIDE
27
12.0 WARRANTY
30
13.0 SERVICE
HISTORY
31
