POWER CONNECTIONS e3 24.3
Product e3EE, e3XE & e3XX
Single Phase Model
Microwave 700W e3EE & e3XE
Microwave 1000W e3XX
Convection heater 3kW/1.5kW e3EE
Convection heater 3kW e3XE & e3XX
Product e3XE & e3XX
Twin Phase & Neutral Model
Microwave 700W e3XE
Microwave 1000W e3XX
Convection heater 3kW e3XE & e3XX
Neutral
Neutral
Heater circuit
Heater circuit
Microwave circuit
Microwave circuit
Control circuit
Control circuit
Live
L1 (Phase 1)
Heater circuit
Heater circuit
Microwave circuit
Control circuit
Control circuit
L2 (Phase 2)
Microwave circuit
