Page 46
46
Service & Parts Manual original Instructions
Part Number 32Z3812 US
Issue 1
ELEC
TRIC
AL
CIR
CUIT
S
1
2
3
4
5
6
7
8
9
10
11
SRB LED’s
23.3
P-Bus - Irregular flashing, indicating data
●
communication with BTS.
Run - Pulsing 1 second flash, indicating that
●
the board has booted up.
12v & 5v - Lit to show voltage outputs from
●
inboard transformer.
Relay & Triac - Lit to show that a signal has
●
been sent to energise that component.
Cooling fan.
1
Convection fan.
2
Stirrers / Turntable.
3
5v supply.
4
12v supply.
5
Heater safety.
6
Heater drive.
7
P-BUS: flashes when data is being sent /
8
received. RUN: 1 second flash.
Oven Door.
9
Microwave safety relay.
10
Microwave drive.
11
