42 Service & Parts Manual original Instructions
Part Number 32Z3812 US
Issue 1
SP
ARES &
REPL
A
CEMENT
Exploded
BOM No.
Part
Number
Description
Qty
Per
Oven
Unit
1-10
Ovens
11-50
Ovens
51-
100
Ovens
1st Aid/
To Go
Box
Service
Centre
kit
1 105005 M3 CAGE NUT 9 EA 9 27 54
55 DX0021 RHS CASEWORK 1 EA 0 1 2
56 DX0022 LHS CASEWORK 1 EA 0 1 2
57 DX0031 CAVITY SHELF RUNNER 4 EA 2 6 12
58 DX0035 STEAM PIPE 1 EA 1 3 6
59 DX0058 HOT BOX 2 MOTOR SEAL 1 EA 0 1 2 1
60 DX0059 CAVITY 2 HOT BOX SEAL 1 EA 0 1 2 1
61 DX0083 FRONT TRIM SEAL 1 EA 0 1 2
62 MC3175 OVEN TRAY 2 EA 2 6 12
63 MC3215 TRAY HANDLE 1 EA 0 1 2
64 30Z5008 DIODE PCB ASSY 1 EA 1 3 6 1 1
65 PSA288 STIRRER MOTOR ASSY (PINNED) 1 EA 1 3 6 1
66 PSA291 STIRRER ASSY (PINNED) 1 EA 1 3 6 1
67 PSX202 DOOR ASSY 1 EA 0 1 2
68 PSX209 HOT AIR MOTOR SUB-ASSY 1 EA 1 3 6 1
69 SA374 CAST WAVEGUIDE ASSY 1 EA 0 1 2
70 / 72 PSR101 EIKON DOOR HINGE KIT 1 EA 1 3 6 1
71 / 73 PSR102 EIKON M/SWITCH BRACKET KIT 1 EA 1 3 6 1
74 PSX203 TURNTABLE DRIVE ASSY 1 EA 1 3 6 1 1
75 SX305 REAR CASEWORK ASSY 1 EA 0 1 2
76 SX306 MAG EXHAUST DUCT ASSY 1 EA 0 1 2
77 SX307 DOOR SEAL ASSY 1 EA 1 3 6 1 1
78 SX309 AIR FILTER ASSY 1 EA 1 3 6 1 1
79 SX314 WAVEGUIDE AIR DUCT 1 EA 0 1 2
80 SX315 CERAMIC CAT CONVERTER 1 EA 0 1 2
eikon e3 XX - 220Volts 60Hz - USA - Unique Parts
82 30Z1230 60HZ TRANS MULTI TAP 1 EA 1 3 6 1
81 30Z1332 1.05uF CAPACITOR 2500V 1 EA 1 3 6 1 1
84 31Z1255 CABLE GLAND BLACK PG21 1 EA 1 3 6
85 31Z1256 NUT FOR CABLE GLAND PG21 1 EA 1 3 6
DX0104 MAINS SUPPLY LEAD DH (US) 1 EA 1 3 6
2 30Z1445 10A UL Fuse 1 EA 2 6 12 2 4
3 30Z0285 Fuseholder 1 1/4in 2 EA 1 2 4 1 2
8 30Z1443 3A UL Fuse 1 EA 2 6 12 2 4
9 30Z1446 2uf UL Starter cap 2 EA 2 6 12 1 2
13 30Z1455 LV TRANSFORMER 1 EA 1 3 6 1 2
All above oven variations can be fitted with or without Catalytic Converters (see Main List for part no.)
