7
Notes:
• Select models have a
slight curve to the freezer
handle.
• For proper installation, be
sure handle is oriented as shown.
To Install:
1. Align door handle clips
to the studs attached to
the freezer door.
2. Ensure the large hole in
the mounting clip is
positioned to the right
on both ends of the
handle.
Freezer Handle
Handles
Installation
5. Grasp the handle firmly and
slide down.
Plastic Handle
To Remove:
1. Grasp the lower part of the
handle firmly, slide up, lift and
remove from the surface.
4. Rotate the handle so that the
handle is flat against the door.
To Install:
1. Pull both rails out to full
extension.
2. While supporting door
front, hook supports into
slots located on inside of
each slide.
Note: All four drawer bracket supports must be in
the proper slots for the drawer to function properly
(see inset for detail).
3. Lower door front into final
position.
4. Replace and tighten Phillips
screws that were removed
from the drawer slides.
5. Install the lower assembly by
aligning hooks of lower
drawer assembly with rear
rail on freezer drawer.
6. Replace freezer drawers.
Align the large square
notches on outside of the
drawer slides.
3. Ensure the large hole in the
mounting clip is positioned down
on both ends of the handle.
Door
Stud
Note: If not installed, the handle is located in the
interior of the fresh food compartment or attached
to the back of your refrigerator.
To Install:
1. The handles are to be oriented as
shown.
2. Align door handle clip with the
door studs.
