24
Care and Cleaning
To avoid electrical shock which can cause severe
personal injury or death, disconnect power to
refrigerator before replacing light bulb. After
replacing light bulb, reconnect power.
WARNING
To avoid personal injury or property damage,
observe the following:
• Allow light bulb to cool.
• Wear gloves when replacing light bulb.
CAUTION
Replacing Light Bulbs
Freezer Light
1. Remove light bulb.
2. Replace bulb with
appliance bulb no
greater than 40-watts.
Fresh Food Section
The fresh food light bulbs are located at the top of the
compartment and beneath the ice storage enclosure.
The freezer light bulb is located at the top front of the
freezer section.
Fresh food section
upper front
1. Squeeze both sides
of light shield in the
open area while
pulling downward to
remove.
2. Remove light bulbs.
3. Replace with appliance bulbs no greater than
40-watts.
4. Replace light bulb
cover by inserting
tabs on light shield
into liner holes on
each side of light
assembly. Do
not force shield
beyond locking point.
Doing so may damage
light shield.
Fresh food enclosure light
1. Pull cover out, press
along upper edge and
roll light cover up and
forward to remove.
2. Remove light bulb.
Replace with appliance
bulb no greater than
40-watts.
3. Insert lower tabs of light cover into slots of fresh
food liner. Roll upward to snap into slots located
under the ice storage enclosure.
