12
Dispenser Lock/Unlock
The Dispenser Lock/Unlock prevents ice
or water from being dispensed.
To Lock Dispenser:
• Press and hold the Lock/Unlock button for three
seconds. A green indicator light above the button will
illuminate when the dispenser is locked.
To Unlock Dispenser:
• Hold the Lock/Unlock button for three seconds. The
green indicator light above will go out.
Ice and Water
Ice and Water Dispenser
To Use Dispenser
Paddle:
• Choose Water selection
from dispenser control
panel.
• Press a sturdy,
wide-mouthed container
against dispenser paddle.
• Release pressure on
dispenser paddle to stop
water dispensing. A small
amount of water may
continue to dispense and
collect in dispenser tray.
Large spills should be
wiped dry.
Removable Tray
The removable tray at the bottom of the dispenser area
is designed to collect small spills and may be easily
removed for cleaning and emptying purposes.
Important: Removable tray does not drain. Do not
allow tray to overflow. If it does, remove tray and wipe
up overflow.
Notes: If dispenser is active for more than five
minutes, an automatic lock out sensor will shut
down power to dispenser area. See Dispenser
Lock/Unlock for unlocking information.
Note: During initial use of water dispenser and
ice maker, there will be a one to two minute delay
while water tank fills before water dispenses or ice
is made. Discard first 10-14 glasses of water after
initially connecting refrigerator to household water
supply. Additional flushing may be required in
some households where water is of poor quality.
To Dispense Ice and Water:
• Select Water, or Cube ice mode by pushing button
on dispenser control panel. A green light above
button indicates mode selection.
• Press container against dispenser paddle. When
dispensing ice, hold container as close to chute as
possible to reduce spraying.
Water Cube
Dispenser
Paddle
Removable Tray
Automatic Ice Maker
Connect the ice maker to the
water supply as instructed on
pages 8-9. Proper water
flow and a level refrigerator
are essential for optimal
ice maker performance.
Ice Storage Bin
The ice storage bin is
located below the
automatic ice maker in the
upper left side enclosure
of the fresh food
compartment.
To Remove:
• Depress the button on the lower right of
the ice storage bin to release from the enclosure.
Continue pulling until resistance is felt. Lift up front
of ice bin and remove. Press the switch on the front
of the ice maker to turn the ice maker off.
Important: Do not remove ice storage bin without
pressing ice maker switch to OFF. Removing ice
storage bin while ON could result in ice falling into the
ice storage bin enclosure, blocking the dispenser and
disabling the bin from being locked into proper
position.
ON/OFF
switch
Note:
Access to the ice storage bin will be limited
with the left fresh food door opened at 90 degrees.
Move cabinet forward to enable door to open
sufficiently for ice storage bin access.
To Install:
Important: Ice bin must be
locked in place for proper ice
dispensing. If necessary, turn
auger driver behind ice bin
counterclockwise to properly align
ice bin with auger driver.
Cont.
Auger Driver
