CatEye CC-MT300 [Mity 3] - Manual (Page 3)

5
2
1
3
®
5
4
7
3
(2)
(1)
3
6
(2)
(1)
3
6
2mm
6
1
2
4
5
6
3
8
7
0
9
9
9
9
1
(3)
1
8
(4)
3
2
1 4
5
CAT EYE MITY3
CC-MT300
1 Bracket
2 Wire
3 Sensor
4 Sensor Bands-A
5 Sensor Band-B
6 Magnet
7 Sensor Band Rubber Pad
8 Bracket Rubber Pad
9 Nylon Tie
0 Sensor Band Screw
Attach the sensor temporarily.
Note: Sensor Band-A
(Small) --------- 11Ш-26Ш
(Large) --------- 21Ш-36Ш
Align the magnet's center(1) and the
sensor's marking line(2). Make sure of
approx. 2mm clearance between the magnet
6 and sensor 3 .
Test
Slide the main unit onto the bracket according to " How to Attach Main Unit to
Bracket" (below). Make sure the computer is fully attached to the bracket. Spin the
front wheel and check if the speed display appears. (If not, adjust the relative posi-
tions of magnet and sensor again.) Fasten the sensor securely, and remove the
main unit.
Secure the wire along the fork with the
nylon ties
9 , and wind it round the brake
cable(3) up to the handlebar.
Note: Allow enough wire length in the
area marked with in the illus-
tration, to insure full movement
and unhindered operation of the
handlebar.
Test the alignment of the magnet and sensor with the main unit attached.
How to Attach Main Unit to
Bracket
Slide main unit onto the bracket from front until
it clicks into position. To remove, pull it off for-
ward while pushing down the lever(4).
E
