38
Preset Filter Cycles 500DZ
The first preset filter cycle starts at 8:00 AM and ends UÊ
at 10:00 AM. The second preset filter cycle starts at 8:00
PM and ends at 10:00 PM.
For non-circ systems, low-speed pump 1 and the ozone
UÊ
generator (if installed) run during filtration.
For circulation systems, the circ pump and the ozone
UÊ
generator (if installed) run 24 hours. In hot environments,
the circ pump may turn off for 30 minute periods, except
during filter cycles. At the beginning of each filter
cycle, all other equipment will run briefly to purge the
plumbing.
Optional Filter Cycle Programming 500DZ
You are not required to change the filter cycles, but if you UÊ
wish to, press “Time”, “Mode/Prog”, “Mode/Prog” within
3 seconds. SET START FILTER 1 (AM) will appear. Press
“Warm” or “Cool” to reset the filter start time.
Press “Mode/Prog” to see
UÊ SET STOP FILTER 1 and
adjust the time with “Warm” or “Cool” as done above.
Press “Mode/Prog” to see SET START FILTER 2 (PM)
and proceed as above. Press “Mode/Prog” to see
SET STOP FILTER 2 and proceed as above. Press “Mode/
Prog” to confirm.
LOCKING THE PANEL 500DZ
Press “Time”, “Blower”, and “Warm” within 3 seconds. UÊ
The Panel is now locked. To unlock the panel, press the
“Time”, “Blower”, and “Cool” within 2 seconds.
Note: On some systems, “Jets 1”, instead of “Blower”, is
UÊ
used in Lock/Unlock sequences .
LOCKING THE TEMPERATURE 500DZ
Press “Warm”, “Time”, “Blower”, and “Warm” within UÊ
3 seconds. The “Warm” and “Cool” buttons are now
disabled. To unlock the temperature, press “Time”,
“Blower”, and “Cool” within 2 seconds.
Note: On some systems, “Jets 1”, instead of “Blower”, is
UÊ
used in Lock/Unlock sequences.
OZONE
For non-circ systems (if installed) runs during filtration.
For circulation systems (if installed) runs 24 hours.
FILTER CYCLES
Preset Filter Cycles 500Z
The first preset filter cycle begins 6 minutes after the UÊ
spa is energized. The second preset filter cycle begins 12
hours later. Filter duration is programmable for 2, 4, 6, or
8 hours or for continuous filtration (indicated by ). The
default filter time is 2 hours.
To program, press “Temp”, then “Jets 1”. Press “Temp” to
UÊ
adjust. Press “Jets 1” to exit programming.
For non-circ systems, low-speed pump 1 and the ozone
UÊ
generator (if installed) run during filtration.
For circulation systems, the circ pump and the ozone
UÊ
generator (if installed) run 24 hours. In hot environments,
the circ pump may turn off for 30 minute periods,
except during filter cycles. At the beginning of each
filter cycle all other equipment will run briefly to purge
the plumbing.
Preset Filter Cycles 500SZ
The first preset filter cycle begins 6 minutes after the UÊ
spa is energized. The second preset filter cycle begins 12
hours later. Filter duration is programmable for 2, 4, 6, or
8 hours or for continuous filtration (indicated by
).
The default filter time is 2 hours for non-circ systems and
4 hours for circ systems.
To program, press “Warm” or “Cool”, then “Jets 1”.
UÊ
Press “Warm” or “Cool” to adjust. Press “Jets 1” to
exit programming.
In hot environments, the circ pump may turn off for
UÊ
30 minute periods, except during filter cycles. At the
beginning of each filter cycle all other equipment will run
briefly to purge the plumbing
GS Panel -- 500 Series and Operation (cont.)
