WEBSHARE 243WM
80
APPENDIX B
Technical Features
Protocols IP, NAT, ARP, ICMP, IGMP, DHCP(server, client and
relay), RIP1/2 , SNTP client, UPnP, Telnet server, SNMP
LAN port 4 x RJ45 10/100 Base-T ports
WAN port RJ-11 (1 port ADSL)
Antenna 3*5dBi Antennas (R-SMA)
External buttons Reset/Power Button
LED Indicators Power, System, WLAN, 4 X Lan, ADSL and PPP
Wireless IEEE802.11g/IEEE802.11b (WDS)
Standard ADSL Compliance ANSI T1.413 Issue 2, ITU-T G.992.1(Full Rate DMT), ITU-
T G.992.2 (Lite DMT), ITU-T G.994.1 (Multimode), ITU
G.992.3 (G.dmt.bis), ITU G.992.5 (G.dmt.bisplus)
Protocols ADSL RFC2364(PPPoA), RFC2516(PPPoE) and RFC1483
ATM ATM AAL2/AAL5 and ATM service class : CBR, UBR,
VBR-rt, VBR, ATM Forum UNI 3.0, 3.1 and 4.0
Firewall Static Packet Filtering, URL Filtering, MAC Filtering and
NAT
VLAN Per Port VLAN
QoS QoS: The Prioritization functions allow you to specify which
packets have priority and should not be delayed,
and/or which packets have low priority and should be
moved to the end of upload queues.
IP Throttling: Using IP Throttling, bandwidth limits can be
enforced on any system within your LAN, or even on a
particular application
VPN Pass Through
Input Power 12V DC @ 1A
Power Consumption < 9watts
Agency and Regulatory CE
Dimensions 175 x 129 x 39 mm3
Weight 350g
Operating Temperature 0° to 40°C
Storage Temperature -10° to 70°C
Operating Humidity 5-95% non-condensing
