PT-L735NT
Micro-Portable LCD Projector
S P E C F I L E
Dimensions (W x H x D): 248 x 115 x 359 mm (9-25/32˝ x 4-17/32˝ x 14-5/32˝)
(not including protruding parts)
Weight: 4.2 kg (9.3 lbs.)
Operating environment: Temperature: 0° – 40°C (32°–104°F)
Humidity: 20% – 80% (no condensation)
Remote control unit: Power supply: 3 V DC (AAA battery x 2)
Operation range: Approx. 7 m when operated from directly in front of the signal receptor
Dimensions (W x H x D): 33 x 168 x 40 mm (1-9/32˝ x 6-19/32˝ x 1-9/16˝)
Weight:
108 g (3.8 oz.) (including batteries)
Wireless card: Standard: IEEE802.11b
Modulation: Direct sequence spread spectrum (DS-SS) system
Transmission system: CCK (11 Mbps/5.5 Mbps), DQPSK (2 Mbps), DBPSK (1Mbps)
Transmission speed: 11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps
Operating range: Outdoors: 50 m (11 Mbps), 80 m (5.5 Mbps), 120 m (2 Mbps/1 Mbps)
Indoors: 30 m (11 Mbps), 50 m (5.5 Mbps), 80 m (2 Mbps/1 Mbps)
* Operation range differs depending on environments.
Frequency range: 2,412 MHz – 2,484 MHz
Channel: 1 – 14 ch
Supplied accessories: Power cord
Full-function wireless remote control with laser pointer
Batteries for remote control unit
RGB cable (3.3 m/9´10˝)
AV cable (3.3 m/9´10˝)
USB cable (3.3 m/9´10˝)
Carrying bag
Optional accessories: Replacement lamp unit: ET-LAC735
Ceiling mount bracket: ET-PK735
Wide conversion lens: ET-LEC701
Wireless mouse receiver: ET-RMRC2
Weights and dimensions shown are approximate.
Specifications subject to change without notice.
As of May 2003
1: Average values of delivered models, measured in compliance with “Guidelines for LCD Projector Measuring Procedures
and Measuring Conditions (June 1999)” by the Japan Business Machine Makers Associations (JBMA).
2: ANSI lumens is the measuring method of the American National Standards Institute IT7.228. Since there is no uniform
method of measuring brightness, specifications may vary among manufacturers.
