SE-4200/4400 WATER FILTRATION SYSTEM
20
P/N 1010852 Rev. C 04/06
REPLACEMENT PARTS - SE-4200/4400 (continued)
Item Part
Description
Qty.
No.
Item Part
Description
Qty.
No.
1 1001073 Label Control Panel
1
2 5550100 Enclosure Control-upper
1
5 7000434 SE Series 3 Board Controller
1
Replacement Kit
6* 304P113 Screw, FLTHD #4-40 x 1 15/16”
4
8* 308P151 Sems Screw #8-32 X 5/16
8
9 4060376 Fuse 6 Amp-250vac
1
10 4010187 Transformer 230v/12v
1
11 4060375 Fuse Block 1-pole
1
12* 306P113 6-32 x 0.1875 Slotted Truss Head
2
13 4060378 Block Terminal-6 Pole
1
14 4060361 Bus Bar Contact (4 Pole)
2
15 0503876 Bracket Transformer
1
16 0400329 Rubber Grommet
2
17 4010200 Transformer 115/230-24vac
1
18* 308P103 Scr Mach #8-32 X 3/8” Sltrshd
6
20 5550101 Control Enclosure-lower
1
21 0021461 Inlet/Drain Bracket Weldment
1
22* 325P109 Screw Hexcap 1/4-20 X 1/2”
12
22a* 3250154 Lock Washer, 1/4”
12
23 0400330 Bushing Snap 1 1/8”
2
25 0503996 Clamp Inlet/drain
2
26 2190127 Union End Cap
4
28 0011991 End Cap Union Connector Assy.
4
29 7000405 O-Ring Replacement Kit
1
30 7000406 4200 Cartridge Replacement Kit
1
7000407 4400 Cartridge Replacement Kit
1
31 2190130 Tee 3/4” Npt
6
32 2190132 Nipple 3/4” Npt X 5” Lg
2
33 2190139 Adaptor 1 1/2” To 3/4” Npt (SE-4400) 2
2190131 Adaptor 1 1/4” to 3/4” NPT (SE-4200) 2
34 2190141 Union Adaptor 3/4”
2
35 2190124 Nipple 3/4” Npt
6
36 0504007 Clamp Permeate
1
37 2190126 90° Elbow 3/4” Npt
2
38 0504006 Bracket Permeate
1
39 4060304 Terminal Block 3-pole
1
40 0700634 Power Cord-intl/harmonized
1
0700463 Power Cord Domestic
1
41 0400251 Strain Relief - Cord Connector
1
42 0504039 Bracket Mounting-40” Cartridge
1
43 4060377 Cable Tie Mount W/adhesive
5
44 2070117 Nipple Close 3/4” Npt
4
45 0504042 Plate Cover
1
47 4040171 N.O. Solenoid Valve-3/4” Npt
3
47a 4040172 N.C. Solenoid Valve 3/4”
2
48* 310P178 Screw Hex Bolt #10-32 X 3/8
12
49 2190135 Plug Pipe 3/4” Npt
2
52 1001080 Label Wiring Diagram
1
53 0700646 Wire Harness SE-4400
1
0700644 Wire Harness SE-4200
1
0700619 Wire Set Addendum 120 V
1
0700622 Wire Set Addendum 230 V
1
54* 306P103 Screw Mach 6-32 X 3/8” Lg Sltrshd
1
55 0400138 Lock-nut Conduit-1/2” Npt
1
56* 306P123 Screw Mach #6-32 X 7/8” Slrndhd
2
57* 306P101 Nut Hex #6-32
2
58* 308P103 Scr Mach #8-32 X 1/4” Sltrshd
12
64* 308P185 Screw Tap #8 X 3/8”
4
65 1001130 Label Filter Cartridge
1
66** 5550102 Bag, Hardware Control Enclosure
1
*Only available in packages of ten.
** Not Shown
