Page 38: How to configure individual events continued
MasterSwitch Power Distribution Unit User’s Guide
34
Event-Related Menus and Options
How to Configure Individual Events
Event mask
settings
From the evntlist.htm page, to reconfigure actions for an event:
1. Click the link (the current hexadecimal code) for the event.
2. Enter a new hexadecimal code as an event mask to reconfigure
the bits that control the actions for the event
3. Click
Apply
.
The bits are numbered
0
to
23
, from left to right.
Note:
Bit
5
and bits
14
through
23
are unused. Make sure these bits
are always set to
0
.
Bits
0
to
3
represent the event’s severity:
Bit
4
and bits
6
to
9
enable (
1
) or disable (
0
) event logging
.
and trap
receivers for the event:
Bits 10 to 13 enable (1) or disable (0) e-mail recipients for the event:
Continued on next page
Settings for Bits 0 to 3
Severity
0000
No severity
0001
Informational
0010
Warning
0011
Severe
Bit number
Action enabled or disabled for the event
4
Logging the event.
6
Sending traps to Trap Receiver 1
7
Sending traps to Trap Receiver 2
8
Sending traps to Trap Receiver 3
9
Sending traps to Trap Receiver 4
Bit number
Action enabled or disabled for the event
10
Sending e-mail to recipient 1
11
Sending e-mail to recipient 2
12
Sending e-mail to recipient 3
13
Sending e-mail to recipient 4
