MasterSwitch Power Distribution Unit User’s Guide 15
Menu Items
Network
TCP/IP
The TCP/IP section of the Network menu displays settings for the
MasterSwitch PDU and allows you to configure the following TCP/IP
settings.
TFTP/FTP
For control of file transfers, the TFTP/FTP section allows access to the
following menu items on the TFTP/FTP menu for the TFTP and FTP
Client and the FTP Server.
Continued on next page
Item Description
System IP The IP address of the MasterSwitch PDU
Subnet Mask The network subnet mask
Default Gateway The local default gateway (router address)
BOOTP
Enables or disables BOOTP requests for TCP/IP settings at
startup.
Client or
Server
Menu Item Definition
TFTP Client Remote Server IP:
The network address of the TFTP server
used for downloads.
FTP Client
Remote Server IP:
The network address of the FTP server used
for downloads.
User Name: The user name for access to the FTP server.
Password: The password for access to the FTP server.
FTP Server
Access: Enable or Disable FTP server access.
Port:
The TCP/IP port on which the FTP server for
the MasterSwitch PDU is located.
Default: port 21
