7.6 Specifications
Video specification
Resolution:
640 x 480 pixel
Sensor:
Color CMOS sensor
Lens:
f: 6.0 mm, F: 1.8
Gain control:
Automatic
Exposure: Automatic
White Balance:
Automatic
Image (Video Setting)
Compression: M-JPEG
Image frame rate:
CIF, QCIF, VGA @ 30fps
Support different frame rate for different connections depending
on connection bandwidth: Lowest/Low/ Medium/High /Highest
Compression rate:
Auto/20/15/10/7/4/1
Frame rate:
160x120/320x240/640x480
Video resolution:
Outdoor/Indoor/50Hz/60Hz
Audio
MIC Input:
Internal MIC (mono)
Compression: ADPCM/PCM
Hardware Interface
LAN Connector:
One RJ-45 port, 10/100M auto-sensed, Auto-MDIX
Communication protocol:
HTTP, FTP, TCP/IP, UDP, ARP, ICMP, DHCP, PPPoE, DDNS,
SMTP, UPnP
CPU: ADMtek
5120
RAM: 16MB
Flash ROM:
4MB
Power Supply:
5VDC/2.5A, 100~240VAC, 50/60Hz
Power consumption:
6 Watt max.
LED
Indicator:
Power
LED
(Blue)
Activity
LED
(Orange)
I/O port pin assignment:
Input:
1 set, 2-pin (photo relay; Active High: 9~40VDC; Dropout: 0 VDC)
Output:
1 set, 2-pin (photo relay, Close circuit current: 70mA or 100mA;
30Ohm; Open circuit voltage: 240 VAC or 350VDC)
RS-485:
Half duplex (to control external pan/tilt device)
Software
Browser:
Internet Explorer 5.0 or above;
Netscape
6.0
or
above
Application Software:
IPView Pro
