Testing Machine and Electronic Control Functions
51 F8208801 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
NOTE: On models equipped with a rotation sensor,
“
xxx ” will represent RPM’s and it will alternate
with the other display.
Table 16 (continued)
Production Test Cycle Quick Reference Chart
Display Test Mode Comments
“oFLo” Warm Fill to Overflow
“xxxF” degrees F or
“xxxC” degrees C
depending on the
Fahrenheit/Celsius
programming parameter Heat water to 110°F or display
temperature xxx is degree temperature. This step skipped if not temp-
sensor-equipped. Heater turned off when temperature reached.
“LoAg” then “ xxx” Reduced Wash Speed Forward
with no agitation action This step skipped on 2 Speed models.
“ Ag” then “ xxx” Wash Speed Forward with no
agitation action
“ rAg” then “ xxx” Wash Speed Reverse with no
agitation action
“drAI” then “ xxx” Drain Distribution Speed
“PUrg” Factory Valve Purge
“SP 1” then “ xxx” Extract Speed #1 “very low” This step skipped on 2 Speed models.
“SP 2” then “ xxx” Extract Speed #2 “low” This step skipped on 2 Speed models.
“SP 3” then “ xxx” Extract Speed #3 “medium” This step skipped on 2 Speed Design 1 and 2 models and
L-Speed Design 4 models.
“SPIn” (2 Speed models)
then “ xxx” This step skipped on VFD models.
“Prdn” End of test Turn Power off
Table 16
