30 ASUS ME-99 User’s Manual
Connectors
3. H/W SETUP
3. HARDWARE SETUP
3) Universal Serial Bus Ports 1 & 2 (Two 4-pin USB)
Two USB ports are available for connecting USB devices.
Universal Serial Bus (USB) 2
USB 1
4) Parallel Port Connector (25-pin PRINTER)
You can enable the parallel port and choose the IRQ through Onboard Parallel
Port (see 4.4.2 I/O Device Configuration).
NOTE: Serial printers must be connected to the serial port.
Parallel (Printer) Port (25-pin Female)
5) Serial Port COM1 Connector (9-pin COM1)
A ready-to-use serial port is provided for a mouse or other serial devices. A
second serial port is available using a serial port bracket connected from the
motherboard to an expansion slot opening. See Onboard Serial Port 1 in 4.4.2
I/O Device Configuration for settings.
Serial Port (9-pin Male) COM 1
