41
Opening the server
Caution! Before you proceed, make sure that you have turned
off your system and all peripherals connected to it. Read the
“Preinstallation instructions” on page 39.
You need to open the server before you can install additional
components. The bezel and left side panel are removable to allow
access to the system’s internal components. Refer to the following
sections for instructions.
Opening the bezel door
A security lock secures the bezel door to protect your system unit
against unauthorized access.
To open the bezel door:
1 Insert the key into the lock and turn it clockwise until it points to
the unlock icon
.
2 Pull open the bezel door.
Removing the bezel door
The bezel door is attached to the chassis by screwless hinges.
To remove the bezel door:
1 Unlock the bezel door with the key (when necessary).
2 Open it to a 45° — 90° angle (1).
3 Press the release switch (2).
