Panasonic KXTS730S User Manual
Quick guide, Kx-ts730, Connections

PQQW14728XA
F0305-2055
D
Please read the operating instructions for further details.
Connections
Note:
L
Use only the included Panasonic AC adaptor PQLV10 (9V/850 mA).
L
The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel
warm during use.)
L
The AC adaptor should be connected to a vertically oriented or floor-mounted AC outlet.
Do not connect the AC adaptor to a ceiling-mounted AC outlet, as the weight of the
adaptor may cause it to become disconnected.
L
The unit will not work during a power failure.
To disconnect the
interface cable, pull
out the cable while
pushing the tabs.
AC adaptor
Telephone
line cord
To single-line
telephone jack
(RJ11C)
To power outlet (120 V AC, 60 Hz)
Hooks
Interface cable
1
2
Bottom of the
interface box
Interface box
Fasten the
AC adaptor
cord.
Fasten the
interface cable.
Model No.
KX-TS730
Quick Guide
E-PQQW14728XA.fm 1 ページ 2005年6月3日 金曜日 午前10時4分
