Moving Washer to a New Location
To prevent damage while moving the washer, the
shipping materials MUST be reinstalled.
Reinstallation of Shipping Materials
Disconnect washer from electrical supply.
Remove front access panel by removing two screws.
Place the shock sleeves on all four shock absorbers.
Refer to illustration.
Insert hooked end of shipping brace into the open slot
of the motor mount. Attach with bolts and washers.
Refer to illustration.
Reinstall front access panel.
Refer to Installing the Washer section for proper
procedures whenever the washer is moved and is ready
for reinstallation.
H336I
1 Shock Sleeves
2 Motor Mount
3 Bolts and Washers
4 Hooked End of Shipping Brace
1
2
3
4
