Alliance Laundry Systems H011C - Manual (Page 13)

Installing the Washer
11 685980
Step 5: Remove the Shock
Sleeves and Shipping Brace
Remove front access panel by removing the two
screws.
Remove 9/16" bolts and washers from shipping brace
with wrench and remove brace. Remove shock sleeves
by pulling on the yellow rope.
Remove label from front side of front access panel and
place on back side of front access panel.
NOTE: The shipping brace, bolts, washers, and
shock sleeves should be saved and MUST be
reinstalled whenever the washer is moved more
than 4 feet. Do not lift or transport washer from
front or without shipping materials installed. Refer
to Moving Washer to a New Location section for
instructions.
Store the shipping materials in the bag provided in the
accessories bag. Save materials for use whenever the
washer is moved.
Reinstall front access panel.
Step 6: Wipe Out Inside of
Wash Drum
Before using washer for the first time, use an all-
purpose cleaner, or a detergent and water solution, and
a damp cloth to remove shipping dust from inside
washer drum.
Step 7: Plug In the Washer
Refer to section on Electrical Requirements and plug
the washer in.
Step 8: Check Installation
Refer to Installer Check on the back cover of this
manual and make sure that washer is installed
correctly.
H336I
1 Shock Sleeves
2 Motor Mount
3 Bolts and Washers
4 Hooked End of Shipping Brace
1
2
3
4
H337I
H008I
H337I
D254I
