HARDWARE PACKAGE CONTENTS
M
2
Jam Nut, 1/2"
N
32
Lock Washer, 5/16"
O
8
Flat Washer, 3/4" (2 for shims)
P
8
Spacer, 1/4" Long
Q
1
Spacer Tube, 3.90" Long
R
2
Spacer Tube, 1.00" Long
S
1
Spacer Tube, 2.38" Long
T
2
Spacer Tube, 5.29" Long
U
1
Shoulder Spacer
V
1
Handle Grip
W
8
Split Plastic Bearing
A
2
Hex Bolt, 1/2" x 3-1/2" Lg.
B
3
Hex Bolt, 1/4" x 1-3/4" Lg.
C
6
Hex Bolt, 3/8" x 1-1/4" Lg.
D
6
Hex Bolt, 3/8" x 1" Lg.
E
8
Hex Bolt, 5/16" x 3/4" Lg.
F
32
Carriage Bolt, 5/16" x 3/4"
G
1
Hitch Pin
H
1
Hair Cotter Pin
I
2
Nylock Jam Nut, 1/2"
J
12
Nylock Nut, 3/8"
K
40
Nylock Nut, 5/16"
L
3
Nylock Nut, 1/4"
Key
Qty.
Description
Key
Qty.
Description
A
C
D
E
B
F
H
G
I
J
K
L
N
O
P
Q
R
SHOWN FULL SIZE
NOT SHOWN FULL SIZE
S
V
U
W
M
T
