5-20 Chapter 5: BIOS setup
5.4.6 Chipset Configuration
The Chipset Configuration menu allows you to change the advanced chipset
settings. Select an item then press to display the sub-menu.
North Bridge Configuration
Advanced Chipset Settings
WARNING: Setting wrong values in below sections
may cause system to malfunction.
North Bridge Configuration
South Bridge Configuration
Configure North Bridge
features.
BIOS SETUP UTILITY
Advanced
BIOS SETUP UTILITY
Advanced
North Bridge chipset Configuration
Memory Remap Feature [Enabled]
PCI MMIO Allocation: 4GB To 3584MB
DRAM Frequency [Auto]
Configure DRAM Timing by SPD [Enabled]
Initiate Graphic Adapter [PEG/PCI]
PEG Port Configuration
PEG Port [Auto]
ENABLE: Allow
remapping of
overlapped PCI memory
above the total
physical memory.
DISABLE: Do not allow
remapping of memory.
Memory Remap Feature [Enabled]
Allows you to enable or disable the remapping of the overlapped PCI memory
above the total physical memory. Enable this option only when you install 64-bit
operating system.
Configuration options: [Disabled] [Enabled]
DRAM Frequency [Auto]
Allows you to set the DDR operating frequency.
Configuration options: [Auto] [667 MHz] [800 MHz]
Configure DRAM Timing by SPD [Enabled]
When this item is enabled, the DRAM timing parameters are set according to the
DRAM SPD (Serial Presence Detect). When disabled, you can manually set the
DRAM timing parameters through the DRAM sub-items.
Configuration options: [Enabled] [Disabled]
Initiate Graphic Adapter [PEG/PCI]
Allows you to select the graphics controller as the primary boot device.
Configuration options: [PCI/PEG] [PEG/PCI]
PEG Port Configuration
PEG Port [Auto]
Configuration options: [Auto] [Disabled]
