ASUS RS100-E5-PI2
4-3
Layout contents
Slots
Page
1.
CPU socket
2-6
2.
DDR2 DIMM slots
2-10
Jumpers
Page
1.
Clear RTC RAM (CLRTC1)
4-4
2.
RAID controller selection (3-pin RAID_SEL1)
4-5
3.
Force BIOS recovery setting (3-pin RECOVERY1)
4-5
4.
Fan mode setting (3-pin CPUFAN_SET1 and CHAFAN_SET1)
4-6
Rear panel connectors
Page
1.
PS/2 mouse port (green)
4-7
2.
LAN port for ASMB3 iKVM
4-7
3.
LAN1 (RJ-45) port
4-7
4.
LAN2 (RJ-45) port w/i ASF function
4-7
5.
VGA port
4-7
6.
Serial (COM1) port
4-7
7.
USB 2.0 ports 1 and 2
4-7
8.
PS/2 keyboard port (purple)
4-7
Internal connectors
Page
1.
Floppy disk drive connector (34-1 pin FLOPPY1)
4-8
2.
ICH7R primary IDE connector (40-1 pin PRI_IDE1)
4-9
3.
Serial Serial ATA connectors (7-pin SATA1-4)
4-10
4.
Hard disk activity LED connector (4-pin HDLED1)
4-11
5.
USB connector (10-1 pin USB34)
4-11
6.
Serial port connector (10-1 pin COM2)
4-12
7.
CPU and system fan connectors (4pin CPU_FAN1, FRNT_
FAN1, REAR_FAN1)
4-12
8.
ATX power connectors (24-pin EATXPWR1, 4-pin ATX12V1)
4-13
9.
System panel connector (20-pin PANEL1)
4-14
10.
System panel auxiliary connector (20-2 pin AUX_PANEL1)
4-15
11.
TPM connector (20-pin TPM)
4-16
