Sony PCG-Z505HSK - Manual (Page 62)

VAIO ® Z505 SuperSlim Pro™ Notebook User Guide #
9
Gently replace the keyboard, then press it into your computer. Be
careful not to detach the cable when lifting the keyboard.
10
Close the computer cover, then tighten the screws on the bottom of
the computer.
11
Turn on the computer.
12
Click the Start button, point to VAIO, and click Sony Notebook Setup.
The Sony Notebook Setup screen appears.
13
Click the About This Computer tab to view the amount of system
memory. If the additional memory is not shown, repeat steps 1-12.
To remove a memory module
1
Follow steps 1 to 5 of “To install a memory module.”
2
Touch a metal object (such as the connector panel on the back of your
computer) to discharge static electricity.
3
Remove the memory module.
4
Follow steps 8 and 9 of “To install a memory module.”
✍
If you cannot reset the keybaord correctly, check that the heat sink has not been moved into
the area where the keyboard must be placed.
