VAIO

®

Z505 SuperSlim Pro™ Notebook User Guide

&

Using the Floppy Disk Drive

You can connect the floppy disk drive to the

(USB) connector on your

computer:

To connect the floppy disk drive

Plug the USB cable from the floppy disk drive into the

(USB)

connector on the computer. The VAIO logo on the disk drive should be
facing up.

To insert a diskette

1

Hold the diskette with the label side facing up.

2

Gently push the diskette into the drive until it clicks into place.

✍

To use another USB device, such as a USB mouse, at the same time, plug it into the

(mini

USB) connector on the left side of the computer by using the supplied conversion adapter.

Floppy disk drive

(supplied)

Attached USB cable

USB connector

Diskette

Floppy disk drive
