Locating Controls and Connectors
%
Right
Bottom
Jog Dial control (page 21)
Power switch
USB connector (page 46)
Infrared port
Ethernet network connector
Phone line jack (page 36)
Air vent
Battery release lever (page 11)
Reset switch
Battery lock lever (pages 9, 11)
1
5
2
6
3
7
4
1
3
2
