Description of Hardware
2-3
• Three RJ-45 ports for connection to a 10BASE-T/100BASE-TX Ethernet Local
Area Network (LAN). These ports can auto- negotiate the operating speed to 10/
100 Mbps, the mode to half/full duplex, and the pin signals to MDI/MDI-X (i.e.,
allowing these ports to be connected to any network device with straight-through
cable). These ports can be connected directly to a PC or to a server equipped with
an Ethernet network interface card, or to a networking device such as an Ethernet
hub or switch.
• One RJ-45 port for connection to an xDSL or Cable modem. This port is fixed at 10
Mbps, full duplex. Use a Category 5 cable to connect this WAN port to a xDSL or
Cable modem.
• One RS-232 serial port to connect to an ISDN Terminal Adapter (TA) or to a PSTN
analog modem.
• One parallel printer port that can be connected to a printer. This printer can then
be shared by any LAN/WLAN users.
• Two antennas (dipole, omni-directional).
WAN Port WAN port (RJ-45). Connect your Cable modem, xDSL modem, or an Ethernet
router to this port.
LAN Ports Fast Ethernet ports (RJ-45). Connect devices (such as a PC, hub or switch) on your
local area network to these ports.
Power Inlet Connect the included power adapter to this inlet.
Warning: The included power adapter is 5 V / 2 A DC. Using the wrong type of
power adapter may cause damage.
Item Description
