8
(US)
2
Attach Rear Cover Top D and Rear Cover
Bottom E to Pillar
A .
1 Attach Rear Cover Top D to Pillar A.
2 Attach Rear Cover Bottom E to Pillar A.
E
D
2
1
Installing the Center Speaker Table (For
Home Theatre Systems only)
1 Attach Arm K to Pillar A with Screw (M4 × 8) Q
(four).
Arm K is adjustable to 4 heights.
2 Secure Shelf L with Screw (M4 × 8) Q (four).
~
• Do not use an electric screwdriver when securing the acrylic
board since it may break if the tightening strength is
excessive.
• The maximum weight capacity is 2 kg (4 lb 7 oz). Do not
place any equipment which exceeds 2 kg (4 lb 7 oz) or 380
mm (15 inches) plate width.
K
Q
1
2
Q
L
