Before assembling

• Be sure to have a Phillips screwdriver that fits the screws prior to

the assembly.

• When using an electric screwdriver, set the torque setting to

approximately 1.5 N·m {15 kgf·cm}.

Design and specifications are subject to change without
notice.

• Verify that all parts are included.
• The parts bags are labeled alphabetically.

Preparing for assembly

Specifications

Dimensions:
mm (inches)

1,022 (40 1/4)

600 (23 5/8)

400 (15 3/4)

163 (6 1/2)

Weight:

45 kg (99 lb 4 oz)

Checking the parts

×1

Pillar

×1

Base

×1

Front Cover

×1

Rear Cover Top

×1

Rear Cover Bottom

×1

Base Cover

×1

Bracket 32” L

×1

Bracket 32” R

×1

Bracket L

×1

Bracket R

×1

Arm

×1

Shelf

×2

Hook

×2

Lock Screw

×8

Screw (M6 × 16)

Screw (M5 Ч 12)

Ч8

×8

Screw (M4 Ч 8)
