1)
Measured under the following conditions:
2)
Reference power output for front, center,
surround, surround back and front high speakers.
Depending on the sound field settings and the
source, there may be no sound output.
Frequency response
Analog 10 Hz – 70 kHz,
+0.5 dB/–2 dB (with sound
field and equalizer
bypassed)
Input
Analog Sensitivity: 500 mV/
50 kohms
S/N 3) : 96 dB
(A, 500 mV
4)
)
Digital (Coaxial) Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
Digital (Optical) S/N: 100 dB
(A, 20 kHz LPF)
Output (Analog)
AUDIO OUT Voltage: 500 mV/1 kohm
SUBWOOFER Voltage: 2 V/1 kohm
Equalizer
Gain levels ±10 dB, 1 dB step
3)
INPUT SHORT (with sound field and equalizer
bypassed).
4)
Weighted network, input level.
FM tuner section
Tuning range 87.5 MHz – 108.0 MHz
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals
75 ohms, unbalanced
Intermediate frequency
10.7 MHz
AM tuner section
Tuning range
Antenna (aerial) Loop antenna (aerial)
Intermediate frequency
450 kHz
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B
: 0.7 Vp-p, 75 ohms
P R : 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
iPhone/iPod section
DC 5V 1.0 A MAX
USB section
Supported bit rate* MP3 (MPEG 1 Audio
Layer-3):
32 kbps – 320 kbps, VBR
WMA: 48 kbps – 192 kbps
AAC: 48 kbps – 320 kbps
* Compatibility with all
encoding/writing
software, recording
devices and recording
media cannot be
guarantee.
Transfer speed Full-speed
Supported USB device
Mass Storage Class
Maximum current 500 mA
Area Power requirements
USA, Canada,
Taiwan 120 V AC, 60 Hz
Europe, Australia 230 V AC, 50 Hz
Area Tuning scale
10 kHz step 9 kHz step
USA, Canada 530 kHz –
1,710 kHz 531 kHz –
1,710 kHz
Europe, Australia,
Taiwan – 531 kHz –
1,602 kHz
