American Standard 9141.035 - Manual (Page 3)

M11
© 2008 AS America Inc. Revised 9/04
WHEELCHAIR
USERS LAVATORY
VITREOUS CHINA
9140.021
FINISHED WALL
267mm
(10-1/2)
FINISHED
FLOOR
1-1/4 O.D. WASTE
SUPPLIES
AS REQ'D.
508mm
(20)
219mm
(8-5/8)
864mm
(34)
SUGGESTED
191mm
(7-1/2)
197mm
(7-3/4)
686mm
(27)
425mm
(16-3/4)
229mm
(9)
C/L
290mm
(11-7/16)
76mm
(3)
(2) 11mm (7/16) DIA.
ANCHOR SCREW HOLES
(2) 54mm (2-1/8) DIA.
HOLES FOR CONC. ARMS
178mm
(7)
178mm
(7)
273mm
(10-3/4)
1-1/4 O.D TAILPIECE
114mm
(4-1/2)
70mm
(2-3/4)
203mm
(8)
267mm
(10-1/2)
156mm
(6-3/16)
165mm
(6-1/2)
67mm
(2-5/8)
44mm
(1-3/4)
1-1/4 O.D. TAILPIECE
168mm
(6-5/8)
*
*
(6) 25mm (1) DIA.
ACCESS HOLES
9140.039
FINISHED WALL
267mm
(10-1/2)
FINISHED
FLOOR
1-1/4 O.D. WASTE
SUPPLIES
AS REQ'D.
508mm
(20)
219mm
(8-5/8)
70mm
(2-3/4)
864mm
(34)
SUGGESTED
197mm
(7-3/4)
191mm
(7-1/2)
686mm
(27)
425mm
(16-3/4)
229mm
(9)
C/L
290mm
(11-7/16)
76mm
(3)
(2) 11mm (7/16) DIA.
ANCHOR SCREW HOLES
(2) 54mm (2-1/8) DIA.
HOLES FOR CONC. ARMS
178mm
(7)
178mm
(7)
273mm
(10-3/4)
1-1/4 O.D TAILPIECE
114mm
(4-1/2)
203mm
(8)
267mm
(10-1/2)
156mm
(6-3/16)
165mm
(6-1/2)
67mm
(2-5/8)
44mm
(1-3/4)
1-1/4 O.D. TAILPIECE
168mm
(6-5/8)
*
*
(6) 25mm (1) DIA.
ACCESS HOLES
MEETS THE AMERICANS WITH DISABILITIES ACT GUIDE-
LINES AND ANSI A117.1 ACCESSIBLE AND USABLE
BUILDINGS AND FACILITIES - CHECK LOCAL CODES.
Top of front rim mounted 864mm (34") from finished floor. NOTES:
* DIMENSIONS SHOWN FOR LOCATION OF SUPPLIES AND “P” TRAP
ARE SUGGESTED.
CONCEALED ARM SUPPORT AS REQUIRED TO BE FURNISHED BY
OTHERS.
FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL WALL SUPPORTS.
IMPORTANT: Dimensions of fixtures are nominal and may vary within
the range of tolerances established by ANSI Standard A112.19.2. These
measurements are subject to change or cancellation. No responsibility is
assumed for use of superseded or voided pages.
BARRIER FREE
