Additional Information 106
Average power consumption (when using the
battery pack)
During camera recording using LCD
with the normal brightness
3.8 W
Operating temperature
0
° C to 40° C (32° F to 104° F)
Storage temperature
-20
° C to + 60° C (-4° F to + 140° F)
Dimensions (approx.)
39 Ч 91 Ч 69 mm (1 9/16 Ч 3 5/8 Ч 2 3/4
in.) (w/h/d)
Mass (Approx.)
230 g (8 oz) main unit only
280 g (10 oz) including the NP-FF51
rechargeable battery pack, MGR60
cassette.
Supplied accessories
See page 12.
Handycam Station DCRA-C100
Audio/Video input/output
10-pin connector
Input/output auto switch
Video signal: 1 Vp-p, 75
Ω (ohms),
unbalanced, sync negative
Luminance signal: 1 Vp-p, 75
Ω (ohms),
unbalanced
Chrominance signal: 0.286 Vp-p, 75
Ω
(ohms), unbalanced
Audio signal: 327 mV, (at output
impedance more than 47 k
Ω (kilohms))
Input impedance more than 47 k
Ω
(kilohms)
Output impedance with less than 2.2 k
Ω
(kilohms)
USB jack
mini-B
i.LINK (MICROMV) input/output
4-pin connector S400
AC Adaptor AC-L25A/L25B
Power requirements
AC 100 - 240 V, 50/60 Hz
Current consumption
0.35 - 0.18 A
Power consumption
18 W
Output voltage
DC 8.4 V, 1.5 A
Operating temperature
0
° C to 40° C (32° F to 104° F)
Storage temperature
-20
° C to + 60° C (-4° F to + 140° F)
Dimensions (approx.)
56 Ч 31 Ч 100 mm (2 1/4 Ч 1 1/4 Ч 4 in.)
(w/h/d) excluding projecting parts
Mass (approx.)
190 g (6.7 oz) excluding the power cord
Rechargeable battery pack (NP-FF51)
Maximum output voltage
DC 8.4 V
Output voltage
DC 7.2 V
Capacity
5.6 Wh (780 mAh)
Operating temperature
0
° C to 40° C (+32° F to 104° F)
Dimensions (approx.)
40.8 Ч 12.5 Ч 49.1 mm (1 5/8 Ч 1/2 Ч 1
15/16 in.) (w/h/d)
Mass (approx.)
45 g (1.6 oz)
Type
Lithium ion
Design and specifications are subject to change
without notice.
