26
∗
When connecting 6 speakers, replace the monaural rear speaker with a center speaker, 2 rear speakers and a
subwoofer.
W O O F E R
L
R
FRONT REAR
C E N T E R
LINE OUT
R – AUDIO 2 – L VIDEO 2
R – AUDIO 1 – L VIDEO 1
1
2
PCM/DTS/
DOLBY DIGITAL
COAXIAL OPTICAL
S VIDEO
OUT 5.1CH OUTPUT
COMPONENT
VIDEO OUT
Y
P B
P R
DIGITAL OUT
D-2 D-1
PCM/DTS/
DOLBY DIGITAL
COAXIAL OPTICAL
DIGITAL OUT
LINE OUT
R – AUDIO 2 – L VIDEO 2
R – AUDIO 1 – L VIDEO 1
SACD/DVD player
or
Front
(R)
Front
(L)
Rear
(R)
Subwoofer
l : Signal flow
Rear
(L)
Amplifier (receiver) with Dolby Surround decoder
Center
Rear *
(mono)
Stereo
audio cord
(not supplied)
[Speakers]
Coaxial digital
cord (not supplied)
(white) (red)
to coaxial or optical digital input
Optical digital cord
(not supplied)
Remove jack cap
before connecting
[Speakers]
or
to audio input
(white)
(red)
