Identifying the parts – Sony DCR-VX1000 User Manual

Page 74

@¶ Carrying handle

@• Microphone

@ª Camera recording lamp

#º Remote sensor (p. 79)

#¡ Hooks for shoulder strap (p. 76)

#™ Lens hood

You can attatch a wide teleconversion lens (not supplied) by removing the lens hood.
To remove the lens hood for attachment of the wide teleconversion lens, etc., loosen the lens hood
fixing screw, and unscrew the lens hood counterclockwise.

#£ REC START/STOP button for low-position recording (p. 13)

#¢ Tape transport buttons (p. 16)

/7> FRAME (direction select/frame-by-frame), &SLOW (slow speed playback),

REC (DV IN) (recording using DV IN connector), πSTOP, 0REW (rewind), ·PLAY

(playback), )FF (fast-forward), PPAUSE

#∞ ND FILTER switch (p. 41)

#§ EXPOSURE button and dial (p. 38)

#¶ FOCUS switch and PUSH AUTO button (p. 32)

#• FADER/OVERLAP button (p. 23)

#ª Focus ring (p. 32)

@¶
@•

@ª

#º

#¡

#™

#£

#¢

#∞
#§

#¶

#•

#ª

Identifying the Parts
