79
DCR-PC7.3-858-174-22 (E,S)
Additional information / Información adicional
English
Specifications
Video camera
recorder
System
Video recording system
Two rotary heads, Helical scanning
system
Audio recording system
Rotary heads, PCM system
Video signal
NTSC color, EIA standards
Usable cassette
Mini DV cassette with logo printed
Tape speed
SP: Approx. 3/4 in. (18.81 mm)/s
LP: Approx. 1/2 in. (12.56 mm) /s
Recording/playback time
SP mode: 1 hour (DVM60)
LP mode: 1.5 hours (DVM60)
Fastforward/rewind time
Approx. 2 min. 30 s (DVM60) (using
with battery pack)
Approx. 1 min. 45 s (DVM60) (using
with AC power adaptor)
Image device
CCD (Charge Coupled Device 1/3”)
Viewfinder
Electric viewfinder (color)
Lens
Combined power zoom lens, 120x
(Digital), 10x (Optical)
Focal distance
f = 5/32 to 1 9/16 in.
(4.0 to 40 mm )
1 1/2 to 15 in. (38 to 380 mm) when
converted into a 35 mm still
camera)
F 1.8 – 2.6
TTL autofocus system inner focus
wide macro system
Color temperature
Auto
Minimum illumination
3 lux at F 1.8
Illumination range
3 to 100,000 lux
Recommended illumination
More than 100 lux
LCD screen
2.5 inches measured diagonally
2 x 1 1/2 in. (50.05 x 37.1 mm)
On-screen display
TN LCD/TFT active matrix method
Total dot number
84,480 (384 x 220)
AC power adaptor
Power requirements
100 to 240 V AC, 50/60 Hz
Power consumption
25 W
Output voltage
DC OUT: 8.4 V, 1.8 A in operating
mode
Battery charge terminal: 8.4 V, 1.4 A
in charge mode
Application
Sony battery pack NP-F100/NP-
F200 lithium ion type
Operating temperature
32°F to 104°F (0°C to 40°C)
Storage temperature
–4°F to 140°F (–20°C to 60°C)
Dimensions (Approx.)
Approx. 2 1/4 x 1 3/4 x 4 1/4 in.
(57 x 44 x 107 mm ) (w/h/d)
Mass
Approx. 6.7 oz (190 g)
Design and specifications are
subject to change without notice.
Input and output
connectors
S video output
4-pin mini DIN
Luminance signal: 1 Vp-p, 75
Ω
,
unbalanced, sync negative
Chrominance signal: 0.286 Vp-p,
75
Ω , unbalanced
Audio/Video output/Headphones
jack
Special minijack, 1 Vp-p, 75
Ω ,
unbalanced, sync negative
327 mV, (at output impedance
more than 47 k
Ω )
Output impedance with less than
2.2 k
Ω /Stereo minijack (ø 3.5 mm)
DV input/output
4-pin special connector
Speaker
Piezo-electric-speaker
Connection
26-pin connector
General
Power requirements
7.2 V (battery insertion input)
8.4 V (26-pin connector)
Average power consumption
5.0 W during camera recording
using viewfinder
6.0 W during camera recording
using LCD screen
Operating temperature
32°F to 104°F (0°C to 40°C)
Storage temperature
–4°F to 140°F (–20°C to 60°C)
Dimensions
Approx. 2 3/8 x 5 1/8 x 4 5/8 in.
(w/h/d) (59 x 129 x 118 mm)
Mass
Approx. 1 lb 2 oz (500 g) ( excluding
the battery pack, lithium battery
and cassette
Approx. 1 lb 6 oz (620 g) including
the battery pack NP-F100, lithium
battery and cassette DVM60
Microphone
Electret condenser microphone,
Stereo type
Supplied accessories
See page 6.
