16 US
2: Connecting the speakers
Before connecting the cords, be sure to
disconnect the AC power cord.
AFront speaker (left)
BFront speaker (right)
CCenter speaker
DSurround speaker (left)
ESurround speaker (right)
FSub woofer * Use the long speaker cords to connect the surround
speakers and the short speaker cords to connect the
front and center speakers.
HDMI
XM
SAT IN DVD IN BD IN OUT
Y
P B /
C B
P R /
C R
AUDIO
IN
VIDEO
IN
SAT
MONITOR COMPONENT VIDEO
AUDIO
IN
VIDEO
IN
AUDIO
IN
VIDEO
IN
DVD
AUDIO
OUT
VIDEO
OUT
VIDEO
OUT
SAT IN DVD IN VIDEO 1 IN MONITOR OUT
VIDEO 1 SUB WOOFER
CENTER
R
L
R
AUDIO
OUT
SPEAKERS
SURROUND
L
FRONT
13/32”
(10 mm)
F D A
B C E
A Monaural audio cord (supplied)
B Speaker cords (supplied)*
A B
B
