116
of the image sensor's effective pixel
count.
* 3 The focal length figures are actual
figures resulting from wide angle pixel
read out.
Output connectors
AUDIO/VIDEO output
10-pin connector
Video signal: 1 Vp-p, 75
Ω (ohms),
unbalanced
Luminance signal: 1 Vp-p, 75
Ω
(ohms), unbalanced
Chrominance signal: 0.286 Vp-p, 75
Ω
(ohms), unbalanced
Audio signal: 327 mV (at load
impedance 47 k
Ω (kilohms)), Output
impedance with less than 2.2 k
Ω
(kilohms)
COMPONENT OUT jack
Y: 1 Vp-p, 75
Ω (ohms), unbalanced P
B
/
P R , C B /C R : +/- 350 mVp-p
HDMI OUT jack
TypeA (19-pin)
Input/Output connectors
LANC jack
Stereo mini-minijack (Ø 2.5 mm)
USB jack
mini-B
HDV/DV jack
i.LINK interface (IEEE 1394, 4-pin
connector S100)
LCD screen
8.8 cm (3.5 type, aspect ratio 16:9)
Total dot number
211 200 (960
× 220)
General
Power requirements
DC 7.2 V (battery pack)
DC 8.4 V (AC Adaptor)
Average power consumption
During camera recording using the
viewfinder with normal brightness:
HDV recording 5.9 W
DV recording 5.7 W
During camera recording using the
LCD with normal brightness:
HDV recording 5.9 W
DV recording 5.7 W
Operating temperature
0 °C to + 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to + 60 °C (-4 °F to + 140 °F)
Dimensions (approx.)
145 Ч 156 Ч 322 mm
(5 3/4
Ч 6 1/4 Ч 12 3/4 in.) (w/h/d)
including the projecting parts
145 Ч 156 Ч 322 mm
(5 3/4
Ч 6 1/4 Ч 12 3/4 in.) (w/h/d)
including the projecting parts with
batterypack NP-F570
Mass (approx.)
1.4 kg (3 lb 2 oz) main unit only
1.6 kg (3 lb 10 oz) including the NP-
F570 rechargeable battery pack,
cassette, and lens hood with lens cover
Supplied accessories
See page 16.
Specifications (Continued)
