Setting Up
56
Hooking up the system (continued)
Note
Keep the AM loop
antenna away as far as
possible from the
player. If you do not,
noise may be heard.
4
Hooking up the antennas
1
Strip the coating from the end of the cable and
twist the wires.
2
Connect the wires of the AM loop antenna and the
FM lead antenna to the terminals.
1 Press and hold the tab of the terminal.
2 Connect the wires to the terminal.
3 Release the tab of the terminal.
Setting up the AM loop antenna
AM loop antenna*
(supplied)
*Reorient the antenna to improve broadcast reception.
**Keep the antenna as horizontal as possible.
FM lead antenna**
(supplied)
